+1(267) 606 1002Belt conveyor with cleats for transporting dried fruit in the food industry: a solution that complies with FDA standards
In the food industry, product conveying must meet strict requirements for hygiene, food safety, and efficiency. Transporting dried fruits from a mixer to a big bag filler requires an adapted system, guaranteeing gentle conveying while respecting FDA standards. The cleated belt conveyor is an ideal solution to meet these needs.
Food Industry Constraints
The food industry imposes rigorous rules to avoid any contamination of food products. Conveyors must therefore meet several criteria:
- FDA-compliant materials: the blue polyurethane (PU) conveyor belt, food-certified, ensures compatibility with food products and ease of cleaning.
- Hygienic design: 304L stainless steel frame and bearings to withstand frequent washing and prevent cross-contamination.
- Gentle conveying: H50 cleats with a 100 mm pitch to prevent breakage and preserve the integrity of the dried fruits.
- Ease of maintenance: adjustable belt tension, removable parts, and casters for easy movement.
Customer Context: An Organic Product Packaging Workshop
A workshop specializing in the packaging of organic food products such as cereals, legumes, and dried fruits needs reliable solutions for conveying and elevating its raw materials to the filling stations.
Equipped with high-performance machinery (mixer, vertical bagging machine, multihead weigher, volumetric weigher), this food sector player relies on a belt conveyor with cleats to ensure continuous flow and preserve the quality of organic products.
Do you have a project?
I am available to advise and support you in your studies.
Guillaume, expert in belt conveyor with cleats
+33 (0)2 99 86 06 22
Contact our expert
Technical specifications of the conveyor
This belt conveyor has been designed for the efficient and safe transport of dried fruits with the following specifications:
Dimensions:
- Useful belt width: 400 mm (total width: 600 mm)
- Infeed length: 1,900 mm
- Central length: 3,600 mm
- Discharge length: 400 mm
- Discharge height: 3,400 mm
- Belt height from ground: 300 mm
Materials:
- Food-grade PU belt with blue cleats, FDA certified and compliant with current regulations
- 304L stainless steel frame
- Stainless steel bearings
- Support on feet with simple tubes and plates
Performance:
- Speed: 35 m/min
- Capacity: 3T/h (density 0.6)
- Motorization: SEW USOCOME
- 304 stainless steel discharge chute
Safety design:
- Compliance with the requirements of the Machinery Directive 2006/42/EC
- Prevention of dried fruit degradation risks thanks to a double inflection
- Easily removable for cleaning and maintenance
Available options for optimal customization
The belt conveyor can be customized according to the specific needs of the installation:
- Side guards (corrugated sidewalls) to prevent product loss
- Casters for easier mobility
- Belt tension release for optimal adjustment
- Outlet chute adapted to the process
- Double inflection for better adaptation to the layout
- Belt offset - optional
Conclusion
The cleated belt conveyor represents an ideal solution for transporting dried fruits in the food industry. Its FDA-compliant design, robustness, and adaptation to the specific constraints of the sector guarantee efficient, hygienic conveying without product alteration. It meets the requirements of industry players wishing to improve their packaging process while ensuring food safety and production efficiency.
